A 3 MAX 5  Product parameters

X.Y axis working motor：DC servo motor

Z axis working motor：Dual voice coil motors

Control panel：5 Inches touch screen

Number of tool clamp：2

Tool type：Cutting knife、Indentation knife、 Paintbrush

Cutting blade type：45°、60°

Edge-following function：OR Code, Dot, Right Angle Scanning

Maximum material width： 370mm

Maximum cutting width： 350mm

Maximum cutting speed： 1600mm/s

Maximum cutting pressure：Left: 800g， Right: 800g

Repeatability accuracy： 0.05mm

Cutting accuracy： 0.05mm

Paper capacity： 150mm

Bottom cabinet capacity： 224L  (700x640x500mm)

Mechanical resolution： 0.02mm

Data connection method： WIFl、USB、Network Port

Software： SignCut

Applicable cutting materials：PVC、PET

Input：100-240VAC 50/60HZ

Power：<100W

Operation temperature：5℃℃-+35℃

Working humidity：45%-75%(Non-condensing)

Host size：790 x 790 x 580 mm

Machine size(Including bottom cabinet)：790 x 790 x 1200 mm

Package size：Host: 970 x 960 x 670 mm Bottom Cabinet: 930 x 900 x 730 mm

Net weight of the machine：Host: 96 KG Bottom Cabinet: 50 KG

Packaging gross weight: Host: 128 KG Bottom Cabinet: 83 KG
